Evaluation Kit Manual - Revision A
The color code for the wires is as follows:
RED 14 gauge wire:
BLACK14 gauge wire:
"+" of power supply
"-" of power supply
Figure 4: Connection to heat sink module
Figure 6: Power supply cable connectors
There is only one correct way to connect this cable to the driver
card. Figure 7 shows how to connect the cable to the driver card.
Note that the cable assembly connector is positioned such that
the screw heads are always facing towards user.
Figure 5: Connection to driver card (cable from device)
In addition, each driver card connects to a power supply by
means of a 36" cable. See Figure 6 for a picture of the 2 types of
connectors on the power supply cable. One end has banana plugs
to facilitate connection to a power supply and the other end has
Figure 7: Power supply cable to driver card
a 2 pin socket block connector.
Confidential ? Luminus Devices, Inc. - All Rights Reserved
Page 4
